Challenger CMC 300HF Cone Crusher

Challenger CMC 300HF Cone Crusher

USD 1 599 998.40
Delivery Location
Payment
Pre-Order
In stock
Save this product for later
Share this product with your friends
ShareSharePin it

Challenger CMC 300HF Cone Crusher

Product Details
Weight: 51 000.00 kg

Product Information

The Challenger CMC 300HF is suitable for use as a tertiary crusher.

  • Supplied with feed hopper with volume of 6.3m3.
  • Supplied with 1 unit x HPY300 cone crusher with 1 unit x 220kW electrical motor.
  • Supplied with Weichai 400kW engine.
  • Supplied with feed conveyor of 1,200mm width.
  • Supplied with main discharge conveyor of 1,200mm width.
  • Equipped with Smart Diesel-Electric capability for direct connection to government supplied electrical grid (if required) or external diesel generator (if required).
  • Equipped with Intelligent PLC Automated Control System for easy operations, real-time monitoring and control.
  • Equipped with portable wireless controller for ease and convenience.
  • Fitted with discharge conveyors that can folded hydraulically for convenient transportation.
  • Capacity: 255TPH @ CSS 25mm
  • Hopper Feed Height: 3,628 mm
  • Machine Weight: 51,000 kg
  • External Dimensions : 17,786 mm x 5,321 mm x 5,504 mm
  • Transport Dimensions : 17,547 mm x 3,200 mm x 4,350 mm


Product Features

SMART DIESEL-ELECTRIC DRIVE

Besides a high performance and powerful Weichai diesel engine onboard electrically driving the crushers and conveyors, CMC Mobile Crushing & Screening Plants are able to be connected to the government supplied electrical grid. This flexibility results in a highly reliable, operationally economical, and environmentally conscious crushing & screening operation.


LARGE FEED HOPPER

Maximised productivity and trouble-free feeding thanks to the high-capacity feed hopper. In addition, in some models, the hopper volume may be optionally increased by hydraulically extending the hopper walls.


INTELLIGENT PLC WITH WIRELESS REMOTE CONTROL

There are fully enclosed steel plate guards over the counter weight assemblies. They are easily removable to allow inspection or maintenance of the counter weights or mechanism.


SCREEN BODY

A simple yet intuitive PLC system guarantees the user optimal control over the initial set-up once the plant arrives on site and during subsequent operation, even via a wireless remote control.


ROBUST STRUCTURAL STEEL CHASSIS

A strong yet compact steel chassis is crucial for the plant to withstand all the tough load-bearing pressures it expects to encounter during normal operations.


HEAVY DUTY TRACKS

Reliable heavy duty tracks that offer superior grip in muddy conditions enable stability and flexible mobility within the site.


Delivery Time

In order to provide you with the most economical prices, the Trimax Online Indonesia prices are based on consolidated bulk shipping whenever possible. Shipping is typically initiated within 3 to 4 months. Depending on your shipping address, please allow additional days in transit for delivery. If you require expedited shipping, please indicate this urgency to telysa@trimaxmachinery.com after you have completed your order and received your order confirmation email. Depending on stock availability, we may be able to accede to your request. You will be advised of additional shipping charges associated with expedited orders and have the option to either proceed or cancel the order.
